Dot Pin Marking Machine for Circumference



This Dot Pin Marking Machine for Circumference (DPM303) model is multipurpose Dot Pin Marking Machine for Circumference suitable for signing on metal material. This size of the material could be suitable under the marking head. Printing scope of this Dot Pin Marking Machine for Circumference is 140 mm  80 mm (150 mm  80mm). Also, this Dot Pin Marking Machine for Circumference supports flat-plain, arc as well as circumferential marking (360 Degree). Further, this Dot Pin Marking Machine for Circumference includes Rotary Fixture. This Dot Pin Marking Machine for Circumference also supports line as well as dot marking. The stylus pin dotting on the surface can be done with high frequency, and the model also supports mark logo formation. This Dot Pin Marking Machine for Circumference could mark character, alphanumeric, date, numbers, series No., VIN codes, logos, graphs, and many more.


Specifications

Controller PC Based
Speed 2-3 alphanumeric /second
Marking Depth 0.1  0.5 mm
Marking Scope 140 mm- 80 mm (150 mm - 100mm)/ 360 Degree
Pin Hardness HRC92
Work Piece Hardness allowed HRC65
Software EtchON DPMCAD (Windows Based Software)
Power 110 ~ 230 V / 50~60 Hz
Application Applicable for Metals & Non Metals
Warranty 12 Months Standard Warranty + 1 Month Extended Warranty

Additional Information

Product Code Dot Pin Marking Machine for Circumferenc
